功能及特點 Function and characteristics

適應加彈機皮輥的專業全自動磨礪，采用機械臂膀完成整盤上料-裝盤自動換盤全功能替代人工工作，最大限度減少工人的勞動強度，采用單片粗密度砂輪脫頭磨礪，提高磨礪尺寸精度和穩定表面光潔度，磨礪尺寸確定方式采

用測量后定值磨礪，機械臂免費保修五年（人工損壞不在內）。

Adapt to the professional automatic sharpening of the roller of the elastic machine, use mechanical arms to complete the whole plate loading - plate loading automatic change plate full function instead of manual work, minimize the labor intensity of workers, use a single coarse density wheel to remove the head sharpening, improve the accuracy of the sharpening size and stabilize the surface finish, the determination of the sharpening size by measuring the fixed value sharpening. Mechanical arm free warranty for five years (manual damage not included).

技術參數及規格 Technial Parameters

電源  power supply  380V+PE

整機功率  Total power  5500W

砂輪 Grinding wheel     250X25mm寬（W)X2pcs

磨頭轉速  Rotating speed of grinding head 0-3200RPM

磨礪精度 Grinding precision   Ra:0.05 - 0.14um

皮輥盤裝載數 Roll tray load number  每盤24只  24 per plate

產量 Yield  120檔files/H

儲 料 Storage  6盤滿盤和6空盤自動交換  6 full disks and 6 empty disks automatically swap
